Input:
6.35 mm (1/4”) unbalanced jack (TS, Tip/Sleeve)
Impedance: 1 MOhms
Send:
6.35mm (1/4“) unbalanced jack (TS)
Max output level : +11dBu
Impedance: 300 Ohms
Return:
6.35mm (1/4“) unbalanced jack (TS)
Max input level : +11dBu
Impedance: 1 MOhms
Directly connected to Output when active
Output:
6.35 mm (1/4”) unbalanced jack (TS)
Max output level : +11dBu
Impedance: 300 Ohms
DI Output:
XLR, balanced
Impedance: 600 Ohms symmetrical, 300 Ohms asymmetrical
Max output level : +11dBu
Protected against Phantom +48V power supply
NOON:
Input and Output/Thru
TRS Jack Type-A
Adapter to DIN-5 pin included
Phones:
3.5 mm (1/8“) stereo jack (TRS, Tip/Ring/Sleeve)
Impedance: 39 Ohms
In the:
3.5 mm (1/8“) stereo jack (TRS)
Impedance: 10 kOhms
Pre-amp
Lamp:
PSVANE ECC83
Food
Connector format:
DC Jack 2.1mm, center negative
Input voltage:
12V DC
Consumption:
600mA
Dimensions & weight
Width x Depth x Height*:
19.2cm x 11.7cm x 7cm – 7.6″ x 4.6″ x 2.8″
*Connections and controls includedWeight:
845 g / 1.86 lbs
Easy to use and effective
Innovative new loop indicator displays current loop mode (Rec/Overdub/Play)
Runs on a single 9V alkaline battery (autonomy of approximately 4 and a half hours)
Oper...
Le fleuron de notre collection Stomp Box, le QUANTUMloop, multi-percussion numérique et looper, regroupe 16 échantillons de percussions numériques et un looper avec jusqu'à 5 minutes de temps d'enr...
