The operating mode of the footswitches can be set individually: “latch” or “momentary”.
Stereo input for single stereo cable
Connection possible with other footswitches (FS-5L/FS-5U/FS-6/AB-2)
Compatible with a wide range of instruments, drum machines, guitar amps and electronic devices that feature input compatible with the FS-5L/FS-5U.
Controls: Pedal Switch A, B / POLARITY Switch A, B / Mode Switch A, B
Jacks: Jack A, Jack B (1/4 inch phone type), Jack A & B (TRS 1/4 inch phone type)
Power supply: DC 9 V: Dry battery/9 V 6F22 (carbon), 6LR61 (alkaline)
Consumption: 8 mA (max.)
Accessories: Dry battery/9 V (6F22), Owner's Manual
DIMENSIONS AND WEIGHT
Width188 mm, 7-7/16 inches
Depth91 mm, 3-5/8 inches
Height43 mm, 1-3/4 inches
Weight470 g, 1 lbs. 1 oz.
