The HeadAmp6 is a full-featured six-channel stereo headphone amplifier that includes six auxiliary inputs to enable separate "plus-me" mixes on each headphone channel.
Each output channel has a dual-function balance control that will pan between the left and right inputs of the main signal bus, or vary the mix between the main stereo signal bus and auxiliary input for that respective channel.
Each output channel includes one front and two rear 6.35mm TRS stereo headphone jacks for easy installation and quick hookup capability. The Mono, Mute L and Mute R selection buttons on each channel select between four operating modes; 1) Stereo, 2) Mono left, 3) Mono right, 4) Mono both (left and right) for versatile monitoring solutions. Independent output level controls on each channel customize control levels.
Input options include balanced XLR and 1/4" TRS inputs with matching "Thru" jacks for connecting multiple units. An additional 1/4" TRS Direct In stereo jack on the front panel for quick patch replacement of Rear panel inputs are included for quick insertion of any stereo source. The master volume control sets the level of the master signal bus. Precision eight-segment LED level metering on the main bus and four-segment indicators on each output channel provide visual feedback of signal level at all key points.
Main characteristics
Six independent high-power headphone amplifier channels Dual-function balance/mix control per channel Front-panel stereo auxiliary input for each channel Multiple monitoring settings per channel Individual output level control per channel Four-way precision metering LED segments per channel Master volume control with eight LED segments Direct input jack on front panel One front-mounted and two rear-mounted headphone jacks per channel Connects and drives up to 18 headphones simultaneously Main inputs and outputs XLR and 1/4″ Parallel main outputs for use on multiple units
