Not only for bands and DJs, MG Series mixing consoles can easily accommodate a truly impressive range of applications, from portable PA to fixed installation. Now, with MGP's new digital features and superior sound, the possibilities are endless.
Overview :
16 mic inputs with 48V phantom power and HPF per channel
24 line inputs (16 mono and 4 stereo)
6 AUX sends + 2 FX sends
4 GROUP buses + ST Bus
2 Matrix output
1 mono output
Preview :
Mixing capacity
Mixer channels - 24 line inputs (16 mono and 4 stereo)
GROUP - 4 GROUPS Bus + ST Bus
AUX - 6 AUX sends + 2 FX sends
MATRIX - 1 Matrix out
Integrated processors - FX1:REV-X(8 PROGRAM, PARAMETER command)/ FX2:SPX(16 PROGRAM, PARAMETER command)
I/O
Microphone inputs - MIC: 16 (HPF INPUTS: 100Hz 12dB/oct)
Phantom Power - 48V Phantom Power per channel
Line inputs - LINE: 16 mono + 4 stereo, CH INSERT: 16 RETURN: 1 stereo
Digital I/O - USB Device, iPod / iPhone
General specifications:
Total harmonic distortion - 0.02% (20Hz-20kHz@ +14dBu)
Frequency response - +0.5/-1.0dB 20Hz - 20kHz, refer to nominal output level @1kHz
Hum and noise level
Equivalent Input Noise: -128 dBu Equivalent Input Noise
Residual output noise: -94 dBu Residual output noise
Crosstalk - - -74dB @ 1kHz
Power supply - 100-240V 50Hz/60Hz
Power consumption - 86W max
Dimensions
L - 819mm (32.2")
H - 169mm (6.7")
D - 565mm (22.2")
Net weight - 15.5 kg (34.2 lbs)
