I/O box with 32 remotely controllable MIDAS preamps, 16 outputs and AES50 networking with KLARK TEKNIK SuperMac technology
Digital mixing has revolutionized almost the entire live performance production workflow. The ultra-affordable S32 digital stage box bridges the gap between on-stage talent, the Front of House (FOH) console and the rest of the world with its lightning-fast, rock-solid performance!
The S32 is an extremely versatile 32 x 16 digital stage box with MIDAS remote controllable mic preamps, KLARK TEKNIK AES50 connectivity and a host of other professional-grade features, all at a price everyone can afford! Rugged enough to withstand the rigors of the road, the S32 takes up just three rack slots and connects to FOH with a single, cost-effective Cat 5e cable, such as the KLARK TEKNIK NCAT5E-50M. Now you can have the missing link between stage and FOH at a fraction of the cost of competing systems.
Features :
- 32 fully programmable mic preamps, designed by MIDAS, for audiophile sound quality
- 16 analog, servo-balanced XLR outputs
- AES50 network ports featuring KLARK TEKNIK's SuperMAC networking feature for ultra-low jitter and latency
- ULTRANET Connectivity for the BEHRINGER P16 personal monitoring system for in-ear applications
- Audio and digital control connectivity for TURBOSOUND speaker systems with ULTRANET networking capability
- Automatic AES50 scene split mode when connected between BEHRINGER X32 Series FOH and monitoring consoles.
- Two AES50 ports for cascading additional S16, SD16 or SD8 stage boxes with no merging or router required
- 2 AES-3 ports (AES/EBU), for direct connection of PA system controllers with digital inputs
- Dual dual ADAT outputs providing 16-channel digital output over two optical TOSLINK connectors
- Mute All function for silently muting all inputs on stage
- MIDI input/output for two-way communication between the BEHRINGER X32 Series console and on-stage MIDI devices
- Remote operation via shielded CAT5e cable up to 100 m in length.
- USB connector for system updates via PC
- "Planet Earth" switching power supply for maximum flexibility (100 - 240 V~), noise-free audio, superior transient response and low power consumption to save energy
- Built like a tank, but compact, all-steel 3U rackmount chassis
