Problem: An artist needs to hear themselves through headphones exclusively or mixed with the output of a mixer, CD player, tape deck, or other line-level stereo source. Only the mic signal, however, should be sent to the main mixer.
Solution: Connect MyMONITOR between the mic and line source and the mixer. The mic and line monitor levels can then be adjusted for mixing and volume using the headphones. Only the microphone signal will go on the board. And because MyMONITOR can be mains or battery powered, the device can be used on a large stage or anywhere there is no mains outlet nearby. Dynamic or condenser mics can be used since phantom power is passed through the Mic Thru jack on the mixer or other source.
SPECIFICATIONS:
- Signal-to-noise ratio: 90 dB
- Gain: 15 dB (1/4 in), 50 dB (XLR)
- Maximum input level: -20dB microphone, 40dB monitor
- Output impedance: 10 ohms
- Power supply required: 12V DC (adapter included) or 9V battery
- Power: LED indicator
- Dimensions: 4.5x2.75x1.5 inches (112mm x 72mm x 40mm)
- Weight: 590 g (1.3 lb)
