DC5 link
DC5 Link is a professional, small and very flat power supply for effects pedals with 5 isolated sockets. Measuring only 31 mm high, it fits under the Pedaltrain nano, mini, new nano+ plates and all metro cards. It offers voltages of 9, 12 or 18V and has a total output current of 900mA. The top two switchable 9 or 12V outlets can power two Strymon, Eventide, or two other mid-to-high current pedals. The center output in 18V setting can power one or two dirt pedals, Pigtronix, MXR or other 18V pedals. The two lower 9 or 12V configurable jacks can power two or more standard low-current pedals when used with Split Flex or 3-way daisy-chained Flex. In 12V setting with Stack Flex, they will power a 24V pedal. If necessary, the 5 isolated sockets will give you 9V DC in the default setting switch position.
5 insulated sockets with 9, 12 or 18V
Total output current of 900mA
Two powerful sockets, 300mA each
A configurable 18V socket
High efficiency toroidal transformer
Short circuit protection of all sockets
Advanced LED monitoring of each outlet
Operation on 120 or 230V mains voltage
Detachable AC power cord
DC5 easily adds 5 additional isolated outlets to another link power supply
Total of 10 flexible cables included
Split Flex to power two pedals from one included jack
Super flat, fits under Pedaltrain nano, mini, the new nano+ and all metro cards
Compatible with Temple Audio cards
All crankset mounting hardware included
Output 1-2: 9 or 12V DC / 100mA each
Socket 3: 9 or 18V DC / 100mA
Output 4-5: 9 or 12V DC / 300mA each
Size: 130 x 88 x 31 mm (excluding removable rubber feet)
Weight: 0.7kg
Warranty period: 5 years worldwide
Order number:
DC5 link CIOKS DC5 link – Professional power supply for effects pedals with 5 isolated sockets
In the box:
CIOKS DC5 Link power supply
AC power cord
10 flexible cables:
Type 1 – black with center negative DC jack 5.5/2.1 mm x5
Type 2 – red with center positive DC jack 5.5/2.1mm x1
Type 4 – green with center positive DC jack 5.5/2.5mm x1
Type 5 - 3.5mm jack plug positive black tip x1
Type 6 – black with 9V battery clip x1
Split Flex type 1 – black, powers two pedals from one socket x1
Bottom bracket mounting hardware: 2 screws and a hex wrench
Manual
Product sheet (drilling guide)
Flexible guide
