The DXR15-MKII achieves a maximum SPL of 134 dB and full bandwidth by combining a powerful Class D amplifier with a high-power woofer and Yamaha's cutting-edge technologies.
Less weight, more power
Improved Custom-Designed Transducers: All DXR-MKII series transducers have been meticulously selected and painstakingly customized to deliver optimal performance. The high-power woofers deliver very low distortion and defined deep bass, while the newly equipped, larger and much lighter 1.75" HF compression drivers produce precise midrange and high frequencies up to 20 kHz with lower weight.
Wide Dispersion Constant Directivity Tweeter: The larger HF transducer is mounted on an all-new 90? constant directivity tweeter. x 60?, designed to minimize the deterioration of the radiation pattern in oblique directions, unlike more traditional alarms. This can help achieve a more ideal coverage area without irregularities. With the new constant directivity, wide dispersion horn, sound develops in a more rectangular pattern providing 90? horizontal coverage. at 60, with wide frequency sound projected to the edges of the coverage area.
1100W High Efficiency Class D Amplifiers
New compact high-power DXR mkII amplifier modules: All DXR mkII series loudspeakers feature highly efficient Class D amplifiers optimally designed to match the DXRmkII's HF and LF drivers. These high-performance amplifiers provide the highest audio output in their class with 1100W of power, producing an impressive SPL of up to 134dB. They also provide a very fast attack and superior transient response, which greatly contributes to the incredible audio performance of these speakers.
Integrated 3-channel mixer
The DXR mkII series features a flexible integrated mixer with a variety of inputs, making it ideal for simple vocal/instrumental amplification. With its flexible input/output, the DXR mkII Series can include a complete sound reinforcement system or integrate seamlessly into a setup using DZR or DXS Series speakers.
Versatile Line-Level and Mic Input Capability: The DXR mkII integrated mixer can handle up to three simultaneous inputs. It accepts mic and line level inputs, allowing you to connect to a variety of sources, from microphones to line level instruments and portable audio devices. In the MIC position, an HPF is automatically activated to suppress unwanted low frequencies.
Functionality
• Improved MKII design produces more powerful sound in a lighter, more compact package
• Ultra-precise 48-bit DSP processing for high-definition audio
• Intelligent dynamic control for consistent clarity at any output level
• Extensive DSP protection functions for maximum output capacity
• High efficiency 1100 W Class D amplifiers
• Integrated 3-channel mixer
• Robust and compact ABS housing, finished in matte black
• Symmetrical housing design for mirrored stage monitoring
• Double angle socket
• Hanging points for standard U-brackets and eyebolts (eyebolts not included)
Features
Speaker type: 15", 2-way, bi-amp powered speaker, Bass-reflex type
Frequency range: 49kHz - 20kHz
Nominal coverage: H: 90?, V: 60?
Crossover: FIR-X tuning™ (linear phase FIR filter)
Output Power: Dynamic: 1100W (LF: 950W HF: 150W) / Continuous: 700W (LF: 600W HF: 100W)
Maximum output level (1m; on-axis): 134dB SPL
I/O Connectors: INPUT: XLR-3-31 x1, INPUT2: Phone x2, INPUT3: RCA PIN x 2, THRU:
Processors: D-CONTOUR: FOH/MAIN, MONITOR, OFF
Power Requirements: 100V - 240V, 50Hz/60Hz
Power consumption: 110W
Flight/Mounting Hardware: Top x2, Rear x1 (suitable for M8 x 15mm eyebolts)
Post socket: 35mm with bi-directional functions (0 or 7 degrees)
Dimensions: 700mm x 445mm x 380mm | 27.5" x 17.5" x 15"
Weight: 21.8 kg | 48.1 lbs
Accessories included: UB-DXR10 (U-bracket)
