DESCRIPTION
The Acoustasonic Standard Jazzmaster®'s dual personality offers players a versatile spectrum of acoustic and electric tones in a single creative instrument. Featuring a transverse-braced solid Sitka spruce top, a fully chambered body, inventive Fender and Fishman®-designed analog electronics with volume and blend control, and the familiar feel of a Fender icon, this Jazzmaster® truly sets the standard for the Acoustasonic experience.
Two pickup systems: Fender Acoustasonic Shawbucker™; Fishman® Under-Saddle Transducer
Volume and Blend control
Integrated forearm and back contours
Solid Sitka spruce top, nyatoh body and neck
Rosewood fingerboard and bridge
General
SERIES Acoustasonic® Standard
ORIENTATION Right-Hand
COLOR Black
COUNTRY OF ORIGIN
Neck
NECK MATERIAL Nyatoh
NECK FINISH Satin Urethane
NECK SHAPE Modern "Deep C"
NECK CONSTRUCTION Bolt-On
FINGERBOARD RADIUS 12" (305 mm)
FINGERBOARD MATERIAL Rosewood
POSITION INLAYS Ivory Dot
SIDE DOTS
NUMBER OF FRETS 22
TRUSS ROD Bi-Flex™
TRUSS ROD NUT 4 mm Hex
STRING NUT Graph Tech® TUSQ®
NUT WIDTH 1.6875" (42.86 mm)
NUT MATERIAL Graph Tech® TUSQ®
Body
BODY Nyatoh
BODY FINISH: Satin Urethane
BODY SHAPE: Acoustasonic® Jazzmaster®
TOP: Solid Sitka Spruce
BACK: Nyatoh
SIDES: Nyatoh
BODY STYLE: Acoustasonic
BODY MATERIAL: Nyatoh
ROSETTE: Black/Aged White
Hardware
BRIDGE: Modern Asymmetrical
BRIDGE PINS: Black Plastic
HARDWARE FINISH: Chrome
TUNING MACHINES: Fender® Standard Cast/Sealed with Hex Buttons
STRINGS: Fender® 70CL 80/20 Bronze (.011-.052 Gauges)
STRAP BUTTONS: Standard Chrome
Electronics
CONTROLS: Master Volume, Blend Knob
SPECIAL ELECTRONICS: 2-pickup configuration: Under-Saddle Piezo, Acoustasonic Shawbucker Magnetic
Dimensions
DIMENSIONS: 5.10x15.75x46.50 IN
SHIPPING WEIGHT: 9.7 LB
FRET SIZE: Medium Jumbo
SCALE LENGTH: 25.5" (64.77 cm)
SHIPPING LENGTH: 46.50 IN
SHIPPING HEIGHT: 5.10 IN
SHIPPING WIDTH: 11.80 IN
Accessories
TRUSS ROD WRENCH: 4 mm Hex (Allen)
RECOMMENDED GIG BAG: 0991612406 FE1225 ELECTRIC GUITAR GIG BAG
Miscellaneous
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
COMMODITY CODE: 9207.90.0040
STYLE: Acoustic
