Problem: You need to add 3 mics to a mixer, which only has 1 channel available.
Solution: Insert a ProMIX between the mics and the mixer. Each mic channel on the ProMIX features phantom power and low frequency cutoff selectable via DIP switches plus level control. The balanced XLR line output can be connected to a mic input on the mixer and headphones or a powered monitor can be connected to the Phone/Aux output. And if AC power is not available, the ProMIX also runs on batteries.
SPECIFICATIONS:
- Maximum gain: 60 dB +60 dB
- Input impedance: 600 ohms
- Maximum input level: -14dB
- Maximum output level: +14dB
- Output impedance: 600 ohms
- Total Harmonic Distortion: 0.0002
- Bass filter: -3dB @ 100Hz
- Clearance before saturation: 3dB
- Output phantom power: 12V DC
- Power supply: 12V DC (adaptor) / 2x 9V (batteries)
- Dimensions: 5.625x3.75x1.75 inches (143mm x 92mm x 45mm)
Weight: 1.5 lbs (680 g)
