Vintage sounds inspired by the famous fuzz pedals of the 1960s and 70s
Advanced COSM technology simulating classic fuzz
BOOST command increasing aggression
Ultra-strong BOSS metal housing
BOSS 5-year warranty
Nominal Input Level: -20 dBu
Input Impedance; 1M ohm
Nominal Output Level: -20 dBu
Output Impedance: 1k ohm
Recommended load impedance; 10k ohms or more
Controls: Pedal switch, LEVEL knob, FUZZ knob, MODE knob IndicatorsCHECK indicator (also serves as a battery voltage indicator)
Jacks: INPUT jack, OUTPUT jack, AC adapter jack (DC 9 V)
Power supply: DC 9V: 6F22 (9V) type battery (carbon), 6LR61 (9V) alkaline dry battery, AC adapter (PSA series: optional)
Consumption: 36 mA (DC 9 V)
Estimated battery life in continuous use: Carbon: 3 hours, Alkaline: 10 hours
Accessories: Instructions for use, Leaflets (“Safety instructions”, “Important notes” and “Information”), MODE sticker, Dry battery 006P/9V (6LR61)
Options: AC adapter (PSA series)
DIMENSIONS AND WEIGHT
Width73 mm, 2-7/8 inches
Depth129 mm<, 5-1/8 inches
Height59 mm, 2-3/8 inches
Weight440 g, 1 lbs.
