Easy to use and effective
Innovative new loop indicator displays current loop mode (Rec/Overdub/Play)
Runs on a single 9V alkaline battery (autonomy of approximately 4 and a half hours)
Operation possible on mains adapter (PSA range, sold separately)
Up to 12 minutes of storable stereo recording
Stereo inputs and outputs
Numerous trigger options via external footswitch
Phrases are remembered even when the RC-1 is turned off
SPECIFICATIONS
Nominal input level: -20 dBu
Input impedance: 1M ohm
Nominal output level: -20 dBu
Output impedance: 1k ohm
Recommended load impedance: 10 k ohms or greater
Controls: Pedal Switch
LEVEL button
Indicators: CHECK indicator
Connectors: INPUT A (MONO) jack: 1/4 inch jack
INPUT B jack: 1/4 inch jack
OUTPUT A (MONO) jack: 1/4 inch jack
OUTPUT B jack: 1/4 inch jack
STOP/UNDO jack: 1/4 inch TRS
DC IN power input
Power supply: Alkaline battery • (9 V, 6LR61)
Power adapter (PSA range, sold separately)
• Rechargeable Ni-MH batteries cannot be used. Consumption 85 mA Battery life in continuous use (These figures vary depending on usage conditions.) Alkaline: approximately 4.5 hours
Accessories: User manual
Printed “SAFE USE OF THE APPLIANCE”, “IMPORTANT NOTE”, and “Information”
Alkaline battery (9 V, 6LR61)
Options (sold separately): AC adapter (PSA range)
Footswitch: FS-5U, FS-6, FS-7
DIMENSIONS AND WEIGHT
Width73 mm, 2-7/8 inches
Depth129 mm, 5-1/8 inches
Height59 mm, 2-6/16 inches
Weight440 g, 0 lbs. 16 oz.
