Next-generation BOSS octave pedal with vintage and polyphonic modes, ultra-fast tracking and extended range.
Fusing classic BOSS octave sounds with the latest tracking technology, the BOSS OC-5 sets a new standard in octave pedal performance. Vintage mode recreates the legendary OC-2 mono from 1982, while Poly mode offers numerous improvements for extended range play. And with the addition of a higher octave function, a three-octave range is now available for creative exploration. From fat, bassy mono tones to octave-shifted chords and more, the OC-5 delivers the greatest range, best sound quality, and best playability yet in any octave playing.
Features
- The industry standard octave pedal, updated with improved functions
- New tracking technology allows for more precise response and natural feeling without latency
- Vintage mode faithfully reproduces the mono sound of the original OC-2
- Poly mode for playing chords; the Range knob sets the range of notes where the effect is applied
- Lowest range setting in Poly mode applies the octave effect to the lowest note of a chord only
- New higher octave effect, available alone or combined with lower octave effects
- Mode switch optimizes sound engine for guitar or bass
- Direct outlet for wet/dry installations
- Five-year BOSS warranty
Specifications
Nominal input level: -20 dBu
Input impedance: 1M ohm
Nominal output level: -20 dBu
Output impedance: 1k ohm
Recommended load impedance: 10k ohms or more
Workaround: Buffered workaround
Controls: Footswitch, GUITAR/BASS switch, VINTAGE/POLY switch, DIRECT LEVEL button, +1OCT button, -1OCT button, -2OCT/RANGE button
Indicator: CHECK indicator (also serves as a battery check indicator)
Connectors:
Input jack: 1/4 inch jack
Output jack: 1/4 inch jack
DIRECT OUT jack: 1/4 inch jack
DC IN jack
Power supply: Alkaline battery (9 V, 6LR61 or 6LF22)
Current consumption: 55 mA
Expected battery life with continued use:
Alkaline: Approximately 7 hours
