The USB Phono Plus is the ideal solution for transferring any popular vinyl collection to your computer or laptop. It is also the ideal high-performance audio interface between analog and digital sources. The built-in low-noise RIAA phono preamplifier circuit with high-pass filters (to eliminate noise and rumble) ensures pristine audio capture.
The front-mounted gain control and Signal/Clip LED make it easy to optimize a wide range of analog input sources. The USB monitor/headset provides latency-free monitoring of the input source for easy cueing. The PhonoPlusPS USB can also serve as an audio playback source for any computer or laptop equipped with a USB port. TOSLINK optical input and output as well as an S/PDIF input make the PhonoPlusPS USB an ideal analog/digital audio interface to USB.
The low-noise phono preamplifier IC is highly accurate and RIAA compliant. The Line Out jacks are always connected to the input preamp signal for source monitoring or to enable use as a standalone phono preamp.
Housed in a full black anodized aluminum enclosure, the PhonoPlusPS USB can be powered either by an external power supply or directly via the USB port. To ensure maximum versatility, the PhonoPlusPS USB is fully compliant with the USB 2.0 specification and uses Adaptive USB mode for playback and Asynchronous USB mode for recording. It will work with Windows 98SE/ME/2000/XP/Vista/7 USB audio device drivers as well as native USB compatible Apple OS9.1/OS-X computers.
Features :
- USB connectivity to desktop and laptop computers
- Precise, low-noise RIAA phono preamplifier
*Up to 45 dB of clean gain
- Latency-free monitoring
- S/PDIF or optical to USB and USB to optical interfaces included
- Preamp line output allows stand-by use
- Single Phono Preamplifier
- Recording and production software included
- Compact, stackable, all-aluminum chassis
- Flexible power supply from USB port or external power supply (sold separately)
- Three-year warranty
specifications:
- USB Phono Plus Project Series Specifications:
- Frequency response: 0Hz50kHz, +/- 0.5%.
- THD: 90 dB below clipping
- Input impedance: 47k Ohms/100pf (phono), 270k Ohms (line)
- Maximum input level: 40 mV rms @ 1 kHz (phono), +19dBu (line)
- Maximum gain: 45dB @ 1 kHz (phono), 6dB (line)
- Analog input connections: RCA (preamp / phono / line output)
- Analog output connection: RCA (pre-amplified line output) 1/8 (monitor/headphone output)
- Maximum output level: +6dBu (1.4V rms)
- Filter Type / Response: Switchable, high pass (low cut) 3dB @ 22 Hz
- A/ND/A: 16-bit, 44.1 kHz or 48 kHz, USB selectable from computer 0.4 ms A/D delay at 44.1 kHz
- Digital audio interface; TOSLINK Opto In to USB, TOSLINK Opto Out from USB, S/PDIF coaxial (RCA) In to USB
- Computer interface: USB 2.0 compatible
- Chassis type: Full black anodized aluminum with integrated rubber sides
- Power requirements: USB bus powered or 7-12V DC or 9-12V AC @ 150mA (external) Either polarity of the tip works with DC power
- Dimensions: 1.85 x 4.6 x 4.5 (in) 47 x 117 x 114 (mm)
- Weight: 1.35 lbs, 0.61 k
