The DJ PRE II (formerly called "Phono MicroPRE") is the ideal solution for connecting a turntable to any low impedance analog line input (mixer, sound card or DAW). The input capacitance can be switched between 100pF and 200pF to optimize the response of your phono cartridge. A switchable high-pass filter eliminates turntable rumble while leaving audio pristine. The front gain adjustment control and signal/clip LED allow you to optimize the DJ PRE II's gain for virtually any input source. The low-noise phono preamplifier IC is highly accurate and RIAA compliant.
Housed in a full black anodized aluminum housing, the DJ PRE II can be powered by a wide variety of external power supplies. If you need to amplify and equalize your vinyl records when you connect to your audio workstation, sound card, stereo or main monitor, the DJ PRE II gives you flawless audio reproduction in a robust and reliable housing.
Features
- High precision/low noise preamplifier
- Switchable low cut noise filter
- Variable preamp gain Signal present/clipping indicator
- Selectable cartridge loading
- RCA preamp outputs
- Robust extruded chassis
Technical characteristics
Frequency response: 10Hz -50KHz, +/-.5dB
Phono EQ Standard: Compliant with RIAA curve
Total harmonic distortion: .01% typical @ 1kHz
Hum and noise: >90dB below clipping
Input impedance: 47k? in parallel with 100pF or 200pF
Maximum input level: 40mVrms @1kHz
Maximum gain: 45dB @1KHz
Input/Output Connections: CR
Maximum output level: +6dBu (1.4Vrms)
Filter Type/Response: Switchable, Low Cut, -3dB @ 22Hz
Power supply required: 7-12V DC or 9-12V AC @150mA
Dimensions: 1.85" x 4.6" x 4.5" (47mm x 117mm x 114mm)
Weight: 1.25 lbs (0.57 kg)
