The Radial StageBug SB-6 is a high-performance 2-channel passive stereo line isolator designed to accommodate balanced and unbalanced signals and effectively work to eliminate noise when used with instruments, consumer devices as well as professional devices.
The SB-6 has 2 TRS inputs and mono TRS type connectors. The unique circuit keeps signals balanced or automatically converts them from high to low impedance (mono TS to TRS) or from low to high impedance (TRS to mono TS) depending on the connector used. Just plug in and the SB-6 does the work for you! Inside, 2 ultra-linear Eclipse transformers with a bandwidth of 20 Hz to 20 kHz. In addition, a -10 dB input pad accommodates high-level sources and a polarity inversion on output B allows phase alignment of stereo signals. As the circuit is passive, no power supply is required, just plug it in and it's ready to go straight away. Like all Radial products, the SB-6 is made in Canada and benefits from a solid steel housing.
Specifications:
• Passive circuit with transformers
• Frequency response 20 Hz - 20 kHz +/-1 dB
• Eclipse Custom Transformers
• Pad -15 dB
• Polarity reversed at 180°
• TRS jack inputs/outputs
• Dimensions: 114 x 47 x 34 mm
• Weight: 0.4 kg
