Sheriff 44 Key Features and Specifications Format: Dual Channel Head Power: High Power: 45 Watts High Power / Fixed Bias 30 Watts High Power / Cathode Bias 6 Watts Fixed Low Power or Cathode Bias Valves: 4 x 12AX7, 2 x EL34 Size ( mm): 480 (w) x 235 (h) x 235 (d), including handle, feet and controls Weight: 12.5 kg / 27.5 lb Additional features: 'Volume I' footswitchable modes and 'Volume II' High and low power output modes Serial effects loop with hard bypass Selectable fixed or cathode bias operation External bias test points and adjustment Protective cover included. One-button footswitch for channel switching included
Two Footswitchable Channels Inputs/Volumes I and II are separate footswitchable channels. Volume I has plenty of overdrive if you want it, with a smoother, more 'vintage' midrange focus. Volume II moves forward a decade or two with more gain, more punchy mids, and tighter bass. Want it cleaner? Simply bring back the volume on your guitar. Post-Phase Inverter Master A PPIMV (post-phase-inverter master volume) is a great option for a traditional voiced amp like this. You can hear and feel the power section more at lower volumes, or you can turn the master all the way up where it is then mostly out of the circuit for that non-master volume amp feel and response. Fixed or Cathode Bias You can run the power section in fixed or cathode bias mode. The first provides maximum free space and clarity; the latter more compression and sag at higher volumes. At lower volumes the cathode bias may sound more "urgent" and dynamic, but push the master and it will start to compress more quickly. Serial Effects Loop A serial effects loop is available for effects fans. It is completely out of the circuit when it is hard bypassed. This is a post-phase inverter master volume amp, so effects can easily overdrive when used in the loop. Our advice is to run the mix/output levels on your effects much lower than you would in the front. External Bias Adjustment Eliminate all the hassle of replacing output valves with the Sheriff 44's external bias measurement and adjustment points. All you need is a new pair of EL34s and a multimeter. It's fast, safe and reliable - you can find full instructions in the amp's manual.
