- Sculpted body
The sculpted mahogany body of the TRBX504 and TRBX505 models provides, in addition to optimum balance, a very unique design.
- Sleeve
The 5-ply neck profile (maple/mahogany) guarantees comfort and reliability. The 5-ply profile inherited from the TRB range is ideal for bassists looking for technique and velocity.
- BB pickups
Designed by YGD (Yamaha Guitar Development), the TRBX300 range pickups incorporate ceramic magnets which deliver a rich, powerful, deep and parasite-free sound. These microphones offer even more comfort thanks to the "thumb rest" concept.
- Electronics（Performance EQ）
The new TRBX300 series is the only one to offer the unique “Yamaha Performance EQ” concept. Thanks to the 5-position switch, it is possible to instantly obtain 5 typical sounds or equalizations (Slap, Pick, Flat, Finger, Solo). The active electronics of this new series of basses are complemented by 2-band equalization to refine your settings and "sculpt" your sound more precisely.
- Screwed handle
The TRBX range is based on robust construction and assembly. Nothing is left to chance to guarantee true comfort along the entire length of the fingerboard.
- Easel
The molded bridge is resistant to all situations and maximizes vibration transmission. The space between the strings at the bridge is 19mm optimizing slap attack and finger play.
- Head
The profile of the head and the reliability of its mechanics guarantee great tuning stability and the absence of "parasitic noise".
- Nut
38 mm for the 4 string model. 43 mm for the 5 string model
- Jack base
The metal jack base is a real guarantee of reliability.
General Specifications
| General | Construction | Bolt-on |
|---|---|---|
| Scale Length | 34" (863.6 mm) | |
| Body | Body Materials | Mahogany |
| Body Finish | Gloss Polyurethane | |
| Neck | Neck Materials | Maple/Mahogany 5-Piece |
| Neck Finish | Satin Polyurethane | |
| Fingerboard Materials | Rosewood | |
| Fingerboard Radius | 10" (250mm) | |
| Freight wire | Medium | |
| Number of freights | 24 | |
| Nut materials | Urea | |
| Width @ 0 Freight / 12th Freight | 38.0 / 56.4mm | |
| Thickness @ 1st Fret / 12th Fret | 19.5 / 21.5mm | |
| Electronics | Neck Pickup | Double Coil / Ceramic |
| Middle Pickup | - | |
| Bridge Pickup | Double Coil / Ceramic | |
| Controls | Master Volume, Pickup Balancer, 2-Band EQ (Bass, Treble), 5-Position Lever Switch for Performance EQ | |
| Pickup Switch | - | |
| Hardware | Bridge | Die-cast |
| Thong spacing | 19mm | |
| Tailpiece | - | |
| Tuning Machines | Covered / Die-cast | |
| Pickguard | - | |
| Others | String gauge | D'Addario EXL170SL / 0.045-0.100 |
| Box | - | |
| Special Features | - |
