YORKVILLE / YXL15SP / Sub 15 inches, 1000w from the yxl series

The YXL15SP offers our best ratio of power, performance and value for an active subwoofer. Delivering 500 watts (1000 watts peak) with efficient speaker components, the YXL series is extremely powerful for its size. The YXL15SP can be easily used in any situation, near walls, floors or in networks with multiple enclosures. Description of the YXL15SP : • 1000 watts (peak), 500 watts (program) • Superior DSP processing with component protection • 15" woofer with 3" voice coil • Recessed control panel • Master level control with activity indicator (speaker level adjustment) • 3 operating modes: dynamic, soft and deep • 2 XLR/6.35mm hybrid inputs • 2 XLR Link inputs • 15 mm plywood, latex paint • Robust metal grille, over the entire length YXL15SP Specifications : • System type: Powered woofer • Active or passive: Active • Rated power: 500 W operational power (1000 W peak) • Maximum NPrA: 128 dB peak • Frequency response: 45–100 Hz +/- 3 dB • Woofer(s): 15 inches (3 inch voice coil) • Rated bass power: 500 W operating power (1000 W peak) • Type of bass amplification: Class D • Cooling: Speed-controlled fan • Power cable: Yes • Power switch: Yes • Inputs: 2 main hybrid XLR female/6.35 mm, 2 XLR LINK male • Level settings: Pmain • Equalization settings: Push-button selection; dynamic, soft and deep • Limiter: Multiband excursion, RMS, rail • Feet: Rubber • Handles: 2 on the side • Enclosure materials: 12 mm plywood, metal grille • Grille: Powder-coated steel with fabric • Others: Rubber feet on the bottom and side for stage monitor position • Dimensions (D x W x H): 48 x 46 x 61 cm (19 x 18 x 24 in) • Weight: 28.1 kg (62 lb) EQ and Tone Settings : Dynamic mode (“Punch”) processes the sound so that it is perceived as a more powerful sound, giving less force to the deep bass and more to the upper bass. Smooth mode preserves the original character of the signal, without preference for bass or treble. Deep mode will process the signal to provide a deeper sound, giving more power in the deep bass while retaining the upper bass similar to Smooth mode.
